Cảm biến điện dung IFM IGS232 Inductive sensor

Cám ơn bạn đã quan tâm đến sản phẩm của NTN.
Yêu cầu báo giá xin click vào đây.

Mr. Nam:

0982494745

Model: IGS232

Maker: IFM

Description: Cảm biến điện dung

Cảm biến điện dung IFM IGS232 Inductive sensor

Suitable for industrial, mobile, cooling and lubricating applications
High protection rating for the requirements of harsh industrial environments
Flexible use thanks to large operating te...

Product characteristics

Electrical design

PNP

Output function

normally open

Sensing range [mm]

Housing

threaded type

Dimensions [mm]

M18 x 1 / L = 60

Application

Special feature

Gold-plated contacts; Increased sensing range

Application

Suitable for industrial, mobile, cooling and lubricating applications; Industrial applications / factory automation

Electrical data

Operating voltage [V]

10...30 DC

Current consumption [mA]

< 10

Protection class

III

Reverse polarity protection

yes

Outputs

Electrical design

PNP

Output function

normally open

Max. voltage drop switching output DC [V]

2.5

Permanent current rating of switching output DC [mA]

100

Switching frequency DC [Hz]

400

Short-circuit protection

yes

Overload protection

yes

Detection zone

Sensing range [mm]

Real sensing range Sr [mm]

8 ± 10 %

Operating distance [mm]

0...6.48

Increased sensing range

yes

Accuracy / deviations

Correction factor

steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3

Hysteresis [% of Sr]

3...15

Switch point drift [% of Sr]

-10...10

Operating conditions

Ambient temperature [°C]

-40...85

Protection

IP 65; IP 66; IP 67; IP 68; IP 69K

Tests / approvals

EMC

EN 61000-4-2 ESD	4 kV CD / 8 kV AD
EN 61000-4-3 HF radiated	10 V/m
EN 61000-4-4 Burst	2 kV
EN 61000-4-6 HF conducted	10 V
EN 55011	class B

Vibration resistance

EN 60068-2-6 Fc

20 g (10...3000 Hz) / 50 sweep cycles, 1 octave per minute, in 3 axes

Shock resistance

EN 60068-2-27 Ea

100 g 11 ms half-sine; 3 shocks each in every direction of the 3 coordinate axes

Continuous shock resistance

EN 60068-2-27

40 g 6 ms; 4000 shocks each in every direction of the 3 coordinate axes

Fast temperature change

EN 60068-2-14 Na

TA = -40 °C; TB = 85 °C; t1 = 30 min; t2 = < 10 s; 50 cycles

Salt spray test

EN 60068-2-52 Kb

severity level 5 (4 test cycles)

MTTF [years]

1690

Embedded software included

yes

UL approval

Ta	-25...70 °C
Enclosure type	Type 1
power supply	Limited Voltage/Current
UL Approval no.	A001
File number UL	E174191

Mechanical data

Weight [g]

48.3

Housing

threaded type

Mounting

flush mountable

Dimensions [mm]

M18 x 1 / L = 60

Thread designation

M18 x 1

Materials

brass white bronze coated; sensing face: PBT orange; LED window: PEI; lock nuts: brass white bronze coated

Displays / operating elements

Display

switching status

4 x LED, yellow

Accessories

Items supplied

lock nuts: 2
